MOKA SFX H-E03 Triple Head Flame Machine

Save 6%

Warehouse: China Warehouse
Plug: US
Style: 1 unit
Price:
Sale price$328.00 Regular price$349.00

Description

Description

  • The flame machine is professional stage effect equipment with the newest LCD design.
    The machine can be controlled by DMX 512 and is easy to control. However the machine does not include a DMX 512 controller, it needs to be purchased separately.
  • The fire machine with high-quality valves and ignition, has a 99% successful ignition rate.
  • This kind of fire machine creates a splendid and beautiful flame, the height of the flame can reach 3.2 meters( 10.5 feet). the flame projected as if the explosion of the atomic bomb can bring the show to the climax.
  • This can be suitable for various television performances, large outdoor disco shows, concerts, parties, etc. It is an important part of the stage effects.
  • With a safe channel, the flame projector won’t jet the fire if you touch the DMX controller by mistake
  • Safety Sensor component, the power will be cut off automatically, and the flame projector stop working instantly when it falls down
  • 3-pin and 5 pins dmx in/out, enhance the signal transmission

Please note :

The machines are sold without a DMX controller, if you need one, please purchase additionally :

Mini Battery DMX Console 24CHs Battery Controller



    Technical Parameter

    • Features:

                1. High-quality valves and ontóris

                2. Instant dashboard display, easy to use

                3. LCD, easy to operate

    • Specification:

               Voltage: AC 110/230V 50~60Hz

               Power: 180W

               Flame height: 3 meters (10 feet)

               Control mode: DMX 512 / electronic control

               Package size: 35*29*37cm

               Net weight: 8 kg

               Gross weight: 9kg



    •  Packing List :

                 Elf spitfire 1 set

                 A signal cable (2 meters)

                 A manual

                 Power cord 1 (1.5 m)

     How To Use

    • Preparation for installation:

               1. Open the box, count the number of accessories, and read the manual carefully.

               2. The machine uses fire-breathing oil (need to purchase separately).

               3. Before use, please check if all parts of the machine are intact.

               4. Check whether the power supply and socket meet the requirements.

               5. Open the door of the machine, then put the fire-breathing oil into the machine, please make sure the oil tank is fixed correctly; after finishing, close the door of the fire-breathing machine and put the machine in a proper position.

               6. If the direct control through the power switch, please press the switch "POWER", and then connect the power of the flame machine, you can manually control the flame output of the machine; please control the output time.

               7. If controlled by the DMX signal, please connect the power and signal line of the flame thrower, and then press the "DMX" switch; set the DMX address, set the DMX address "1" to ON state, complete the setup, and then use the DMX signal line to connect the machine and DMX console; the machine will DMX self-test, the detection light will flash 3 ~ 4 times. When the DMX signal cable is connected, usually the detection light will keep blinking; otherwise, the detection light will not blink.

              8. If there are more fire-breathing machines, you can connect the fire-breathing machines one after another. Please connect the signal cable to the DMX console; then you can use the DMX console to control the work of the flamethrower.

    • Caution:

             1. Before using this machine, please read this manual carefully.

             2. Only use the special 250V / 10A (110V available) three-wire power supply, it should be grounded, do not get the ground and wire together.

             3. When you are not using the machine, cleaning, installing, or removing accessories, the power cord must be unplugged.

             4. Do not place the machine in a rainy or humid environment to use.

             5. Do not put the machine power plug, or cable in water, or other liquids.

             6. Make sure that all parts are well connected before turning on the power of the machine.

             7. To use the machine, note that the vertical height of the room must be at least 5 meters.

             8. If the machine is damaged, please disconnect the power immediately, do not disassemble the machine, and contact the supplier to repair the machine.

             9. The machine is used together with fire-breathing oil (purchased separately).

            10. Do not point the output of the machine (open flame) directly at people or any goods.



    • Attention :

               Before using this product please first read the operating guide.

      Shipping

      • U.S. warehouse: 2-5 working days in the U.S., 7-12 working days in other areas.
      • Spain warehouse: 2-4 working days in Spain, 7-12 working days in other EU regions.
      • Poland warehouse: 2-4 working days in Poland, 7-12 working days in the rest of the EU.
      • China warehouse: 7-15 working days for direct shipment from China.
      • The transportation type depends on the region, and it is uniformly displayed as international shipping.
      • The goods will be sent out within 1-5 working days. After the logistics order number is generated, customer service will send an email to notify you. Please pay attention to the delivery status.
      • If you have any questions, please leave a message.

      Q&A

      • Q: Where can I buy fuel?

                  A: Websites for buying kerosene in various countries:
                  USA:https://www.amazon.com/Valvoline-602373-11-Starting-Fluid/dp/B00PWLS7HU/ref=mp_s_a_1_5?ie=UTF8&qid=1545973834&sr=8-5&pi=AC_SX236_SY340_QL65&keywords=valvoline+starting+fluid&dpPl=1&dpID=31dshM48ZhL&ref=plSrch

                  Europe:  https://www.amazon.de/dp/B007VMGD7E/ref=cm_sw_r_wa_api_i_Y-R5CbDJ8WX0E

                  France:https://france-effect.com/recharge-flamme/recharge-dragon-tower-iii.html



      • Q: If I use this flamethrower, will it cause a fire, or cause the smoke alarm to go off?

                   A: Our fire-breather can be used indoors or outdoors, as long as it is kept at a relatively safe distance, it will not cause a fire or cause the smoke alarm to go off. And our machine is equipped with a safety channel, when the machine is tilted more than 45 degrees, the flamethrower will immediately stop working to improve the safety of use.



      • Q: Do I need to get a security clearance to use your flame machine or floral sprayers?

                  A: From the customers, we have worked with in Europe, America, and other countries, there is no need to obtain security clearance to use our machines.



      •  Q: If the products are broken during the warranty, what should I do?

                   A: Don’t worry, MOKA SFX has a professional foreign trade team and helps you to solve all problems with our products in time, first please send us pictures or videos If there is a problem with the products. We will guide you on how to fix it and provide spare parts for free if needed.



      • Q: How high can the spray be?

                  A: H-E01:Spray1-3M;

                      H-E02:Spray2-4M;

                      H-E03:Spray1-3M;

                      H-E04:Spray5-6M;

                      H-E01A:Spray1-2(LPG Flame machine);

                      H-E03A:Spray1-2M(LPG Triple-head flame machine )



      •  Q: What are the control modes?

                   A: DMX Control and Electric control

                        DMX control means connecting the Dmx cable and then through the Dmx controller to control the machine

                        Electric control means turning on power then working, turning off power then stopping working



      •  Q: What is a safe channel?

                   A: When you use the Dmx controller to control the machine, channel 1 is a safety channel with values of 102-153 open, when the fire projector safe channel opens. By the way, MK-E06 H-E02, H-E01 H-E01A, MK-E02 MK-E02A, these items need to turn on the power first.



      •  Q: What's the spray called? Chemical composition?

                   A: Flame Oil, Flame Liquid Animal repellent Air freshener.

                        Flame oil composition: Methanol 60%, White mineral oil 20%, Butane 15%, Spices 5%.

                        Color Flame oil composition: glycerin 40%, Silicone oil 30%, Butane 20%, Pigment 5%, Spices 5%.



      • Q: How long will spray for one bottle can be used?

                  A: After confirming with the factory,200ml for one flame bottle = Approximately 60-70 seconds of output.



      • Q: What is the dump switch?

                  A: The power will be cut off automatically and the flame projector stop working instantly when it falls down, ensuring the safety of the event.



      • Q: Where can I buy flame oil?

                  A: Can be purchased from your local market and Amazon, or eBay.

                       ①USA Market: pls check the link from amazon https://www.amazon.com/Valvoline-602373-11-Starting Fluid/dp/B00PWLS7HU/ref=mp_s_a_1_5?ie=UTF8&qid=1545973834&sr=8-5&pi=AC_SX236_SY340_QL65&keywords=valvoline+starting+fluid&dpPl=1&dpID=31dshM48ZhL&ref=plSrch

                       ②Europe: pls check the link from Amazon for reference https://www.amazon.de/dp/B007VMGD7E/ref=cm_sw_r_wa_api_i_Y-R5CbDJ8WX0E



      • Q: What should I do if the machine keeps working?

                  A: First of all, please confirm that all procedures with normal operation, it is recommended to cut off the power and operate it again, If fails again, The cause may be a broken valve, please cut off the power, Replace the new valve.



      • Q: What should I do if the machine just sprays oil and doesn’t catch fire?

                  A: In this case, the angle of the ignition pin may be distorted, and the spray nozzle may not be aligned so that the spark cannot be ignited by the ignition pin when the fire spark comes out. Please try to adjust the angle of the ignition pin to align the nozzle and try again.
