Description
Description
- 15W RGB 3in1, high brightness, RGB color, and reasonable laser beam.
- It uses an advanced temperature sensor with a reduction to the right temperature to protect the machine.
- Control models have ILDA, DMX, auto, sound, Self-propelled mode, and master-slave mode can be optional.
- It adopts independent design and production of an integrated power supply, driver, and integrated module.
- The laser's high-speed optical scanner makes it easy to create animated graphics and beam shows, as well as gobo effects.
- Our Advantages:
- Integrated module, module driver board, and power supply are integrated which makes the light small volume, saves transportation costs, and makes it easy to move.
- The whole exterior of the light body uses hexagon socket screws, which make the body plane smooth and bring a good tactile impression. What's more, it is less prone to wear and rust.
- Aluminum case, which does not rust and is more durable.
- The logo was printed by laser, not easy to fall off.
- Silent fan each Moka laser light with 3 silent fans of the 12v pieces makes the laser run smoothly and extends the service life.
Technical Parameter
Specification:
| Parameter | Details |
|---|---|
| Laser Power/Wavelength | R (red): 3200mW 638nm G (green): 4300mW 520nm B (blue): 7500mW 455nm |
| Divergence Angle | ca. 6.5mm / ＜1.3mrad |
| Control Mode | ILDA, DMX512, SOUND (voice control), AUTO (autorun), master-slave mode |
| Laser Light Source | Imported semiconductor diode |
| Modulation Mode | Analog modulation 100Khz |
| Scanning System | DT40 ±30° |
| Input Voltage | AC100-240V, 50/60HZ |
| Shell Material | Aluminum |
| Cooling Method | Air cooling + TEC cooling |
| Working Temperature | -10℃--45℃ |
| Power | 310W |
| Product Size | 34 * 34 * 31.5 cm |
| Weight | 16kg |
| Packing Size | 49 * 44 * 38 cm, 29kg |
Accessories
| Item | Quantity |
|---|---|
| Laser Projector | 1 pc |
| Power Cable | 1 pc |
| Key | 1 pc |
| Interlock Connector | 1 pc |
| User Manual | 1 pc |
Please Note:
We have different power supply plugs, UK plugs, AU plugs, EU plugs, the USA plugs, please let us know the power supply you need, or we will choose everything according to your country.
How To Use
The manual will be with the machine, if the manual is missing, please leave a message on the website, and we will contact you as soon as possible
Shipping
- China warehouse: 7-20 working days for direct shipment from China.
- The transportation type depends on the region, and it is uniformly displayed as international shipping.
- The goods will be sent out within 1-5 working days. After the logistics order number is generated, customer service will send an email to notify you. Please pay attention to the delivery status.
- If you have any questions, please leave a message.
