Description
Description
- The LED stage lifting ball features a novel and aesthetically pleasing high-temperature-resistant engineering plastic shell and a tall cathedral metal body.
- This product is designed and manufactured strictly according to CE standards and complies with the international standard DMX512 signal protocol.
- It can be used independently or online, with features such as fast rotation speed, low noise, and powerful functionality.
- It is suitable for small and medium-sized concerts, theaters, studios, nightclubs, bars, etc.
- 36pcs 0.5W RGB three-in-one high-power LED with a lifespan of 50,000 hours and low power consumption.
- LED dimming: DIM4 technology (using 4096 linear dimming), LED rainbow effect, macro effect, strobe effect, and pulse effect with 20 flashes per second.
- Universal dimming and shading for all colors.
- DMX512/master-slave/sound control/auto blue LCD display.
- If you need to order this light in bulk, please chat with us or send an email to info@mokalighting.com
Technical Specifications
Specification：
| Parameter | 36pcs 0.5W RGB Three-in-One High-Power LED |
|---|---|
| LED Lifespan | 50,000 hours |
| Input Voltage | AC90-240V, 50-60Hz |
| Power Consumption | 150W |
| Control Channels | 10 DMX Channels |
| Control Mode | DMX512/master-slave/sound control/auto |
| Operating Temperature | Work Permit Temperature: -5 to 45 degrees Celsius |
| Light Source | RGB SMD LEDs |
| Dimensions | 35*26*35 cm |
| Weight | Net Weight: 7 kg, Gross Weight: 9.5 kg |
| Fuse Standard | 3.15A/250V |
| LED Ball Diameter | 15/20/25/30cm |
Please Note：
To maintain the light in good condition and extend its lifespan, we recommend regularly cleaning the fixture
| Maintenance and Cleaning |
|---|
| Check screws for tightness and corrosion. |
| Check fixed points and installation points for deformation. |
| Inspect mechanically moved parts for wear. |
| Check power cord for damage. |
| Clean the inner and outer spheres weekly to avoid contamination and ensure sufficient lighting. |
| Clean the fan weekly. |
| Conduct a detailed electrical inspection by an electrician every three months. |
| Conduct detailed inspection and maintenance every three months. |
| Avoid poor circuit contact and overheating. |
| Do not use alcohol and solvents for cleaning. |
How to Use
Please refer to the user manual
| Installation Step |
|---|
| Step 1: Connect the light clamp to the winch. |
| Step 2: Hang the lifter on the truss, clamp it, and correctly use the safety rope. |
| Step 3: Connect the light fixture to the winch. |
Setting DMX Address Code:
| Step | Operation |
|---|---|
| 1 | Press the "Menu" key to select "Set DMX Address," then press the "ENTER" key to enter. |
| 2 | The display will show "Set DMX Address DMX Address: 001." Use the "Up/Down" keys to modify. |
| 3 | Press the "ENTER" key to save and exit, or press the "MENU" key to exit without saving. |
| 4 | The manual will be shipped with the machine. If the manual is not included, please leave a message on the website, and we will contact you promptly. |
Shipping
- From China Warehouse: Direct shipment from China takes 7-20 working days.
- Shipping types vary by region but are displayed uniformly as international shipping.
- Items will be shipped within 1-5 working days. After the logistics order number is generated, customer service will send you an email notification. Please pay attention to the shipping status.
- If you have any questions, please leave a message.
