- Newly upgraded, reinforced body, stronger material, no water leakage
- Dmx/Wireless Remote control.
- Smoke area coverage 3 minutes can reach 70㎡
- 10.5L Large capacity water tank can last for about 1 hour.
- Built-in high-powered smoke heating rod, preheating time of only 5 minutes.
- Water Fog Machine uses 30 ultrasonic atomizers, which make the spray mist more delicate and the smoke thicker.
- Our Advantage:
1. this machine adopts the independent research and development of the switch power supply. It is easy to install, greatly simplifying the machine circuit connection and greatly improving the machine's stability.
2. This machine adopts a self-developed plastic water tank, which will never rust and leak.
3. This product equips a water level line of the water tank. It is easy to see when adding water. It is also convenient for users to know the water level.
4. The water discharge hole of this product is in the front, completely separate from the circuit, there is no circuit burn as leakage, and easy to operate.
Power: 3000w small size
Water tank: 10.5L
Water consumption: half hour 3l
Fuel tank: 3L
Control Mode: dmx/remote control/time & quantity control
Fuel consumption: 1 hour 1L
Heating time: 136 seconds
Area coverage: 3 minutes 70 squares
Net weight: 40 kg
Gross weight: 43 kg
- Packing List for Each Machine:
1pcs fog machine
1pcs Remote Control
1pcs Power Cable
1pcs DMX cable
1pcs 4m pcs hose
1pcs manual book
How To Use
1. Open the main tank first, add 10 liters of water to the main tank; if necessary, add 5 liters of water to the secondary tank (the secondary tank water will be available when the main tank water is used up. 15 liters of water can be used continuously for 1 hour).
2. Add 2L water spray oil to the oil pot. And connect the power supply, if using a remote control, connect a remote receiver; if using a DMX controller, connect a DMX signal cable.
3. After the machine is warmed up for 4-5 minutes, the amount of smoke can be adjusted according to the needs of the situation. Adjust the amount of smoke less than 30%, then the machine mist work; when more than 30% adjustment, the machine mist + smoke work (such as the case can not use too much smoke, you can use water mist).
4. There are two drain valves at the bottom of the airbox. Check whether it is closed (horizontal) before use. If you need to drain after use, open.
- China warehouse: 7-20 working days for direct shipment from China.
- The transportation type depends on the region, and it is uniformly displayed as international shipping.
- The goods will be sent out within 1-5 working days.After the logistics order number is generated, the customer service will send an email to notify you. Please pay attention to the delivery status.
- If you have any questions, please leave a message.
- Q: Can you print my logo on the machine?
A: Yes, you can send us the final artwork of the logo when you order, so we can check if it could be printed on the machine.
- Q: Do you have a certificate for your product? How about the warranty?
A: We all machines pass the CE Rohs fcc EU quality certificate. We guarantee our product for one year from the date of purchase.
- Q: Can you use normal fog liquid?
A: No. If you use normal fog liquid, it creates a fog that floats up. Use only the water-based fog liquid or the low fog liquid.
- Q: How can I get the water base fog fluid/low fog fluid?
A: You can buy it on site. We have waterbased fog liquid/low fog liquid, but it only ships by to the sea. The MOQ is 200 bottles.
- Q: How long is the heating time?
A: Only 136 seconds to preheat the water.
- Q: Does it have a water level display?
A: Yes. clearwater level display. you can see on the side of the machine.
- Q: How long can I use it after filling it with water and liquid?
A: The 10l clear water tank allows 50 minutes of continuous production at 100% without refilling.
The 3l fluid tank allows 3 hours of continuous production at 100% without refilling.
- Q: If the machine runs out of water, will it stop working automatically?
A: Yes, it has auto senses low water and low fluid mist. When the water runs out, the machine makes a didididi. sound to remind you. There is no need to worry about machines running dry, the machine has built-in sensors to detect low fluid levels.
- Q: Can be controlled by remote control?
A: right, full control with 2 Dmx channels, wireless remote control, and digital timer control.
- Q: How long is the tube?
A: We will send the 4m tube for each machine for free. But if you need a longer tube, we can do it. But it will incur additional costs.
