Description
Description
- Diverse Colors and Effects: Features a color wheel with 14 vibrant colors and a bidirectional rotating rainbow effect, along with 17 static gobos and a unique gobo shaking function, suitable for various stage lighting scenarios.
- Rotating Prism Effects: Includes an 8-facet and a 16-facet double-layer rotating prism, allowing bidirectional rotation and layering to create captivating light patterns.
- Precise Adjustable Focusing: Offers electronic linear zoom adjustable from 3 meters to infinity, combined with 0-100% variable motorized focus for flexible beam adjustment.
- Independent Frost Function: Provides 0-100% linear frost adjustment, enhancing the versatility of stage lighting effects.
- High-Precision Beam: With a beam angle of 1.8° and a lens diameter of 160mm, this fixture ensures sharp and clear illumination, ideal for stage and theater lighting needs.
- Multiple Control Modes: Supports DMX512, RDM, sound activation, master/slave, and auto modes, accommodating various lighting control requirements.
- Extensive Movement Range: Features 540° pan and 270° tilt movement with 8/16-bit resolution, ensuring accurate light positioning for any performance setting.
- Waterproof Design: With an IP56 protection rating, this moving headlight is highly resistant to water, making it suitable for outdoor and various performance environments.
Technical Parameter
Specification:
| Parameter | Specification |
|---|---|
| Power Supply | AC 100-240V, 50/60Hz |
| Power Consumption | 600W |
| Light Source | OSRAM 381S lamp |
| Lamp Life Expectancy | 1500 Hours |
| Color Temperature | 8000K |
| Color Wheel | 14 colors + open, bidirectional rotation rainbow effect |
| Gobo Wheel | 17 static gobos + open, with a gobo shaking function |
| Prism | 8-facet prism, (16+8) double-layer prisms, rotatable in both directions and overlay-able |
| Zoom | Electronic linear zoom, distance from 3m to infinite |
| Focus | Variable motorized focus (0-100%) |
| Frost | 0 - 100% Linear frost |
| Beam Angle | 1.8° |
| Diameter of Lens | 160mm |
| Strobe | 0.5-13Hz/s, with random pulse strobe function |
| Dimmer | 0-100% linear electronic dimmer |
| Movement | Pan: 540°, 8/16 Bit movement resolution<br>Tilt: 270°, 8/16 Bit movement resolution<br>Automatically accurate positioning |
| Control Mode | DMX512, RDM, Sound, Master/Slave, Auto |
| DMX Channel | 16CH |
| Protection Rating | IP56 |
| Product Size | 36 x 32 x 56.2 cm |
| Net Weight (N.W.) | 18 kg |
| Carton Size | 46 x 45 x 58 cm |
| Gross Weight (G.W.) | 23 kg |
| Flight Case Size | 81.5 x 48 x 80 cm (2 in 1) |
| Gross Weight (G.W.) | 70 kg |
Please Note:
We have different power supply plugs, UK plugs, AU plugs, EU plugs, the USA plugs, please let us know the power supply you need, or we will choose everything according to your country.
How To Use
The manual will be with the machine, if the manual is missing, please leave a message on the website, and we will contact you as soon as possible
Shipping
- China warehouse: 7-20 working days for direct shipment from China.
- The transportation type depends on the region, and it is uniformly displayed as international shipping.
- The goods will be sent out within 1-5 working days. After the logistics order number is generated, customer service will send an email to notify you. Please pay attention to the delivery status.
- Regarding tariffs, our prices are all tax-free. We will try our best to choose tax-included channels. However, in most countries, customs clearance and tariffs are inevitable. If the customer cannot get the goods due to non-payment of customs duties, we will not return the goods for a refund.
- If you have any questions, please consult customer service and leave a message.
