- With the excellent optical lens of 5 facet prism with bi-direction rotating
- Single high-quality 100W white light bulb
- The farthest direct output distance can reach 25 meters.
- DMX512, Master/Slave, Auto & Sound Active control mode.
- The horizontal scanning angle is 540 degrees, and the vertical scanning angle is 270 degrees.
- Colored disc (13colors + open, with rainbow effect), Pattern plate (13 gobos + open, with rotation and running water effect )
Led source: 100W White LED
DMX channels: 14CH
Pan: 540 degree + fine
Tilt: 270 degree + fine
Color Wheel: 13colors + open, with rainbow effect
Static Gobo Wheel: 13 gobos + open, with
rotation and running water effect
Prism: 5 facet prism with bi-direction rotating
Dimmer: 0-100% smooth linear dimmer
Strobe: 1-20 Hz with pulse effect
DMX signal connection: three-pin XLR input/output
- Please Note:
We have different power supply plugs, UK plugs, AU plugs, EU plugs, the US plugs, please let us know the power supply you need, or we will choose everything according to your country.
How To Use
The manual will be with the machine, if the manual is missing, please leave a message on the website, we will contact you as soon as possible
- China warehouse: 7-20 working days for direct shipment from China.
- The transportation type depends on the region, and it is uniformly displayed as international shipping.
- The goods will be sent out within 1-5 working days.After the logistics order number is generated, the customer service will send an email to notify you. Please pay attention to the delivery status.
- If you have any questions, please leave a message.
- Q : Will the light fixture work without a DMX console?
A :Yes, don’t worry! In addition to DMX control mode, all moving head lights also have self-propelled, sound-activated, manual and other modes.
When there is no DMX console control, you can choose the music sound control mode and the effect is very good.
- Q : If the lamp is broken during the warranty period, how do you operate it?
A : You can rest assured that we have more than 8 years of export experience, and we provide free technical consultation throughout our life.
Moreover, we have a professional after-sales team that can give you information to respond to communication within 1 hour，give you solve solution within 8 hours to help you deal with after-sales problems; but We need your active cooperation and feedback. You can give us feedback on the problem by taking videos and photos, as well as the description of the problem during the operation of the light; we need to confirm which part may be broken, and then we will guide you how to do with step by step, if the problem is more complicated, we also have operation videos to provide guidance; if it still does not work, we will send you the free accessories for replacement, and you only need to pay the freight .
- Q : After the shelf life, how to ensure the stability of the light?
- A : If the product has passed the warranty, we will provide free technical consultation for life. Even after the warranty period, we recommend that customers do regular maintenance and maintenance of the lamps; if there is any problem with the product outside the warranty period, you can describe the problem, shoot videos and pictures, and we will provide you with the corresponding accessories for repairs. You need it here. Bear the cost of accessories and transportation.
