Description
Description
- 5W green laser, high brightness, and reasonable laser beam.
- The laser light has 200 preset patterns for you to choose from.
- It can be projected in green color and at various speeds.
- The control system includes ILDA, DMX512, Sound, Automatic, and Master-slave.
- With sealing design, dustproof, maintenance-free, stable quality, small spot, Analog modulation up to 100k.
Our Advantages:
- Integrated module, module driver board, and power supply are integrated which makes the light small volume, saves transportation costs, and easy to move.
- The whole exterior of the light body uses hexagon socket screws, which make the body plane smooth and bring a good tactile impression. What's more, it is less prone to wear and rust.
- Aluminum case, which does not rust and is more durable.
- The logo was printed by laser, not easy to fall off.
- Silent fan each Moka laser light with 3 silent fans of the 12v pieces makes the laser run smoothly and extends the service life.
Technical Parameter
Specification:
Parameter | Description |
---|---|
Laser Power/Wavelength | Green (G): 5000mW 520nm |
Divergence Angle | Approx. 5mm / <1.3mrad |
Control Modes | ILDA, DMX512, SOUND (sound control), AUTO (self-propelled) |
Laser Source | Imported semiconductor diode |
Modulation Mode | Analog modulation 100kHz |
Scanning System | 35kpps |
Input Voltage | AC100-240V, 50/60Hz |
Cooling Method | Air cooling + TEC cooling |
Working Temperature | -10℃ to 45℃ |
Power Consumption | 165W |
Dimensions | 24.2 × 22 × 25 cm |
Shell Material | Aluminum |
Weight | 8.7kg |
Accessories
Item | Quantity |
---|---|
Laser Projector | 1 pc |
Power Cable | 1 pc |
Key | 1 pc |
Interlock Connector | 1 pc |
User Manual | 1 pc |
Applicable places: DJs, bands, bars, pubs, clubs, skating rinks, KTV, family parties, birthdays, celebrations, weddings, festivals, shopping malls, stores, stores, and other designated places.
- Please Note:
We have different power supply plugs, United Kingdom plugs, AU plugs, EU plugs, the USA plugs, please let us know the power supply you need, or we will choose everything according to your country.
How To Use
The manual will be with the machine, if the manual is missing, please leave a message on the website, and we will contact you as soon as possible
Shipping
- U.S. warehouse: 2-5 working days in the U.S., 7-12 working days in other areas.
- Spain warehouse: 2-4 working days in Spain, 7-12 working days in other EU regions.
- Poland warehouse: 2-4 working days in Poland, 7-12 working days in the rest of the EU.
- China warehouse: 7-20 working days for direct shipment from China.
- The transportation type depends on the region, and it is uniformly displayed as international shipping.
- The goods will be sent out within 1-5 working days. After the logistics order number is generated, customer service will send an email to notify you. Please pay attention to the delivery status.
- If you have any questions, please leave a message.
Q&A
- Q: How do you choose a laser light?
A: According to the different usage scenarios, use different power laser lights.
- For small parties and family gatherings, 1W, 2W, 3W, and 5W laser lights can be enough, because the price is cheap and the operation method is simple.
- For a bar or a club, it is recommended to choose a 10W laser light. According to the area of the bar, it can be equipped with 2-6 sets of equipment. The 10W laser light can carry out complex requirements such as laser engraving patterns, which can meet all the needs of the bar.
- For concerts, music festivals, celebrations, and other activities, it is recommended to choose 20W, and 30W laser lights, which can perform laser engraving and other effects.
-For urban outdoor landmarks, it is recommended to choose high-power laser lights, 30W-100W, depending on specific requirements, if you need more professional guidance, please contact our customer service.
- Q: Do your laser lights have a security key?
A: Yes, we have standard interlock
- Q: Do I need to buy FB4?
A: The laser light has a self-propelled mode with various changes, which can meet most usage scenarios. If you need to customize the effect, you can buy FB4 on the local professional website.
Recommended website: https://pangolin.com/
